O.S. engine MAX-10LA - Three View Drawing

46
(71521000)
(72403050)
(79870030)
(55500002)
(71531000)
(71531010)
NON-BUBBLE WEIGHT
SUPER FILTER
(
L
)
LONG SOCKET WRENCH
WITH PLUG GRIP
LOCK WASHER
(10Sets)
BLIND NUTS
(10pcs. /Sets)
M3
M3
NON-BUBBLE WEIGHT
S
The specifications are subject to alteration for improvement without notice.
23
38.6
11.7
44.3
27.5
23.5
20
62
15.9
23.2
M5x0.8
33.2
11
31.4
38.7 19.2
4- 3.3
2- 2.8
47
MAX-10LA THREE VIEW DRAWING
Displacement
Bore
Stroke
Practical R.P.M.
Power output
Weight
1.76 cc
(
0.107 cu.in.
)
13.44mm
(
0.529 in.
)
12.4mm
(
0.488 in.
)
2,500-18,000 r.p.m.
0.27 ps / 0.27 hp / 17,000 r.p.m.
112g
(
3.95 oz.
)
SPECIFICATIONS
Dimensions(mm)
