Model engines generate considerable heat.
Do not touch any part of your engine until
it has cooled.
Contact with the muffler (silencer), cylinder
head or exhaust header pipe, in particular,
may result in a serious burn.
Keep your hands and face away from
exhaust gas or you will suffer a burn.
Reminder!
Suggested fuel tank capacities are listed opposite.
These will allow 12-13 minute flights.
Locate the fuel tank so that the top of the tank is 5-
10mm (1/4-3/8") above the level of the needle-valve.
Be sure to use a pressurized fuel system by
connecting the muffler pressure nipple to the vent-
pipe of the fuel tank.
Suggested Fuel Tank Capacities
15CV-A
25FX
32SX
approx 100cc
approx 200cc
approx 220cc
FUEL TANK LOCATION
Attention to tank height
•
Fuel level
10mm
11
