O.S. engine MAX-25LA - MAX-10 LA Three View Drawing and Specifications

MAX-10LA THREE VIEW DRAWING
Displacement
Bore
Stroke
Practical R.P.M.
Power output
Weight
1.76 cc
(
0.107 cu.in.
)
13.44mm
(
0.529 in.
)
12.4mm
(
0.488 in.
)
2,500
~ 18,000 r.p.m.
0.27 bhp / 17,000 r.p.m.
112g
(
3.95 oz.
)
■
■
■
■
■
■
10LA SPECIFICATIONS
Dimensions(mm)
23
38.6
11.7
44.3
27.5
2-ø2.8
23.5
20
62
15.9
23.2
M5x0.8
4-ø3.3
33.2
11
31.4
38.7 19.2
35
