O.S. engine max-65ax User Manual

38
ENGINE EXPLODED VIEW
C.M3x16
2
1
3
4
5
6
7
8
9
10
12
11
13
14
15
16
C.M3x8
1-1
Type of screw
C...Cap Screw
79871110 79871160
M3x8 M3x16
CAP SCREW SETS
(
10pcs./sets
)
Code No.
Size
Pcs. used in an engine
Cylinder Head Retaining Screw (5pcs.)
Cover Plate Retaining Screw (4pcs.)
39
ENGINEN PARTS LIST
The specifications are subject to alteration for improvement without notice.
Description
Code No.
No.
Cylinder Head Head Gasket Cylinder & Piston Assembly Piston Pin Piston Pin Retainer (2pcs.) Connecting Rod Carburetor Complete (Type 61D) Propeller Nut Propeller Washer Drive Hub Thrust Washer Crankshaft Ball Bearing (F) Crankcase Crankshaft Ball Bearing (R) Crankshaft Gasket Set Cover Plate Glow Plug No.8 Needle Valve Extension Cable Set E-4010A Silencer Assembly Assembly Screw "O" Ring Pressure Nipple (No.7) Silencer Retaining Screw (C.M4x40 2pcs.)
1
1-1
2 3 4 5 6 7 8 9
10 11 12 13 14 15 16
26904000 26904160 26903000 26606008 27917000 29115000 26981000 45010002 28009002 26908000 29320000 27731000 26901000 27130020 26902000 24625125 26907000 71608001 72200080 26028050 26028120 27414020 22681957 26625210
