OBELAB NIRSIT - Gain Calibration

NIRSIT EYE PC Introduction
7
2.3 Gain Calibration
1 Click Gain Cal Start button to start the calibration on the Gain calibration panel.
2 Click Apply button to register the available channel referred to SNR level (30 DB)
3 Click Gain Cal Stop button to stop calibration on the Gain calibration panel.
4 Check the result for Gain calibration.
No.
Description
1
LD, PD status
2
Information of rejected channel
3
SNR result of 780, 850’s laser detector
