OBELAB NIRSIT - Page 17

NIRSIT EYE PC Introduction
11
No.
Name
Description
1
Measure Start/
Measure Finish
Start measurement/ Finish measurement
2
Baseline
Reset the hemodynamic result
3
Y Axis Set/ Auto
Y Axis scale can be changeable when the value is set. (default
Auto)
Y Axis Scale Range: -0.002~0.002
4
Marker
The marker links to the database.
▪ When the checkbox is selected, the number (1-4) is saved in
the marker region of the database.
Task A Start: The number “1” is saved.
Task A End: The number “2” is saved.
Task B Start: The number “3” is saved.
Task B End: The number “4” is saved.
