12
Ballhead Operation (continued)
Tripod Operation
PANORAMIC BASE
The base of the ballhead can be
independently rotated 360°. Use
the degree markings on the base
of the ballhead to accurately
set up panoramic shots.
1. Twist the pan knob
counterclockwise to
unlock the base.
2. Rotate the base to the desired
position, and then lock the base
by turning the knob clockwise.
LEG LENGTH ADJUSTMENT
To independently adjust
the height of each leg,
do the following:
1. Loosen the twist locks enough
so that the legs can be ad
justed.
Note: Don’t over-loosen
the twist locks.
2. Adjust the leg to the
desired height.
3. Tighten the twist locks to
secure the leg in place.
OPERATION
