17
Figure 4 Side view of the supply lines
Figure 5 Side view of the supply lines
ELECTRIC MOTOR SUPPLY
3-PHASE (3+PE WIRES)
230 V POWER SUPPLY
(2+PE WIRES)
KNOB
BL2.0 CONNECTION
STROKE COUNTER SENSOR
INPUT CONNECTOR
MODBUS CONNECTOR
OUTPUT CONNECTOR
LEVEL CONNECTOR
USB CONNECTOR
