OBL KIT-PRO UL - Environmental Conditions

File: UT-5601 Copyright © - OBL Metering pumps - All rights reserved
18
Figure 6 – Layout
Figure 7 stroke counter sensor and ring
3 ENVIRONMENTAL CONDITIONS
As for installation, the environmental conditions must match the possible use conditions of OBL’s
metering pumps, which can be combined with the KIT PRO.
This product shall be used in Pollution degree 2 Environment.
STROKE
COUNTER
RING (TO BE USED FOR M
AND REMOVED FOR R)
