21
Statistics
Settings
Previous page
Off
Start
Stop
Alarm
Manual adjustment value
Operating frequency
Flow partialisation
Reset
Modbus
3 MENU
3.1 Home page
Figure 8 Home page
3.2 Operating modes
From the home page, click “operating modes” to select the operating mode you need. Each mode
features an input screen (Figure 9Figure 10) and an operating screen (Figure 10).
Figure 9 Input
Figure 10 Operating screen
