26
with active pump. An error is
recorded in the report. The error can
be reset in the alarm log.
FIRMWARE INFO
INFO
UPDATE FIRMARE
EXPORT PARAMETERS
IMPORT PARAMETERS
EXPORT LOG
DELETE LOG
RESTORE TO FACTORY SETTINGS
This screen allows you to interface
with the USB port, through which
you can update the software, import
and export parameters, export and
delete reports, check the software
version, and restore the default
settings of the system. Export the
report before updating the software
so as not to erase the log file from
the system.
MODBUS
MODBUS (YES/NO)
BAUD RATE
ADDRESS
This setting allows you to control the
pump in Modbus.
ANALOG OUTPUT
OUTPUT
Possibility to activate the output of a
proportional analog signal at the
operating frequency.
RELAY
OUTPUT (OFF / START/STOP /
ALARM)
CONTACT (N.O. /N.C.)
This function allows you to use the
relay with a N.O. or N.C. contact.
The output signal indicates the
pump’s status (ON/OFF) or the
presence of an alarm.
DISPLAY
MENU’ LIGHT (ON/OFF)
WORKING COLOUR (GREEN, PINK,
BLUE, AZURE)
CONTRAST (0-100%)
Display settings: backlight activation
while browsing the menus, colour
selection in operating modes,
contrast.
LEVEL
STOP (YES/NO)
CONTACT (N.O./N.C.)
RED ALARM DISPLAY (YES/NO)
START (YES/NO)
CONTACT (N.O./N.C.)
Setting for starting or stopping the
pump remotely (usually from a level
sensor). You can also decide whether
to activate the red display with the
pump at a standstill. This setting
uses the two pins on the level
connector.
REMOTE START/STOP
START/STOP (YES/NO)
CONTACT (N.O./N.C.)
Setting for starting or stopping the
pump remotely. One single pin is
used in this case. The pump starts
when the contact is closed and
