OBL PRO Series User Manual

File: UT-5601 Copyright © - OBL Metering pumps - All rights reserved
23
L/PULSE parameters allow you to set
the characteristics of the meter. The
TIMEOUT parameter considers the
maximum interval between two
subsequent pulses.
MLQ
MLQ
CONCENTRATION
PULSE/L (L/PULSE)
TIMEOUT
When the pump receives an external
input signal sending pulses, it doses
the liquid based on the concentration
value of the liquid and millimetres
per quintal (MLQ) required at
destination. The PULSE/L and
L/PULSE parameters allow you to set
the characteristics of the meter. The
TIMEOUT parameter considers the
maximum interval between two
subsequent pulses.
Pulse
MAXIMUM PULSE VALUE/M
MINIMUM PULSE VALUE/M
MAXIMUM FLOW RATE
MINIMUM FLOW RATE
TIMEOUT
When the pump receives a pulse
input signal, it adjusts the flow rate
based on the value of pulses per
minute received between the
maximum and minimum values. The
TIMEOUT parameter considers the
maximum interval between two
subsequent pulses.
Analog mA
MA MAXIMUM VALUE (20 MA)
MA MINIMUM VALUE (4 MA)
MAXIMUM FLOW RATE
MINIMUM FLOW RATE
RANGE ALARM
The pump adjusts the flow rate
based on an external analog signal
and the maximum and minimum
values set in the inputs.
Analog V
MAXIMUM V VALUE (10 V)
MINIMUM V VALUE (0 V)
MAXIMUM FLOW RATE
MINIMUM FLOW RATE
RANGE ALARM
The pump adjusts the flow rate
based on an external analog signal
and the maximum and minimum
values set in the inputs.
Pause-work
FLOW RATE
OPERATING PERIOD (MIN)
PAUSE PERIOD (MIN)
The pump alternates pause periods
with constant flow rate operation
periods whose duration can be set.
