10
SECTION 4: SPECIFICATIONS
Table 2. Specications for BC700 series cameras
Model BC700 BC700VF BC700VFE
Sensor 1/3" Sony Super-HAD CCD II 1/3" Sony Super-HAD CCD II 1/3" Sony Super-HAD CCD II
Eective Picture Ele-
ments (H×V)
976 (H) x 494 (V) 976 (H) x 494 (V) 976 (H) x 494 (V)
Horizontal Resolution 700 TV Line 700 TV Line 700 TV Line
Minimum Illumination 0.001 lux F1.2 0.001 lux F1.2
0.001 lux F1.2 /
0 lux (with IR LED on)
S/N Ratio More than 52 dB More than 52 dB More than 52 dB
Scanning System 2:1 interface 2:1 interface 2:1 interface
Synchronous System Internal, negative sync. Internal, negative sync. Internal, negative sync.
Auto Electronic Shutter 1/60 s ~ 1/100,000 s 1/60 s ~ 1/100,000 s 1/60 s ~ 1/100,000 s
Gamma Characteristic 0.45 0.45 0.45
IR Distance
65 ft (with Ø5 x 24 PCS
Infrared LEDs)
131 ft (with Ø5 x 42 PCS
Infrared LEDs)
196 ft (with Ø5 x 72 PCS
Infrared LEDs)
IR Status Under 10 lux by CDS -- Under 10 lux by CDS
IR Power On CDS AUTO control -- CDS AUTO control
Video Output 1 Vp-p, 75  1 Vp-p, 75  1 Vp-p, 75 
Auto Gain Control Auto Auto Auto
Power/Current 12 Vdc (+/-10%) / 350 mA 12 Vdc (+/-10%) / 500 mA 12 Vdc (+/-10%) / 800 mA
Lens 3.6mm / F2.0 2.8 - 12 mm manual zoom 2.8 - 12 mm manual zoom
Dimensions (w x h x d)
6.89 x 2.72 x 2.17 in
(175 x 69 x 55 mm)
8.66 x 3.15 x 3.15 in
(220 x 80 x 80 mm)
10.24 x 3.86 x 3.74 in
(260 x 98 x 95 mm)
Weight 29.3 oz (830 g) 38.8 oz (1100 g) 49.4 oz (1400 g)
Storage Temperature
-22 ~ 140 °F
(-30 ~ +60 °C)
RH 95 % max
-22 ~ 140 °F
(-30 ~ +60 °C)
RH 95 % max
-22 ~ 140 °F
(-30 ~ +60 °C)
RH 95 % max
Operating Temperature
14 ~ 122 °F
10 ~ +50 °C
RH 95 % max
14 ~ 122 °F
10 ~ +50 °C
RH 95 % max
14 ~ 122 °F
10 ~ +50 °C
RH 95 % max
