9. Unit set-up
4
1
6
8
9
7
2
3 5
10
13
11
12
13
1. Air discharge
2. Insulated housing
3. Air inlet
4. Door
5. Wheels
6. Hepa lter
7. Prelter
8. Fan
9. Fan safety cover
10. Presostat
11. Door sealing
12. Door lock
13. Filter lock
14. Controller
15. Connection IEC C14 with fuse
