144 Safety manual
Sikkerhetsdataark Océ VarioPrint 2090
Innholdet i dette produktdatabladet er underlagt retningslinjene (se
‘Produktdatablad’ på side 143) i dette kapittelet.
PRODUCT SAFETY DATA SHEET
Océ-Technologies B.V.
Number E-750-a-NL
Date December 2002
Model Océ VarioPrint 2090
Description Electrostatic digital copier/printer, console model, plain paper, organic photoconductive belt,
powder toner, automatic duplexing
Process speed 85 A4 prints/min or 42 A3 prints/min
Dimensions Width 2550 mm
Depth 800 mm
Height 1830 mm
Weight 722 kg
Voltage 230/400 V 3 240/415 V 3 230-240 V
Frequency 50 Hz 50 Hz 50 Hz
Current-rated 5,5/5/-A 5/5/- A 10 A
Building fuse 13 A 13 A 30 A
Power consumption
* plug in 2W
* stand by 525 W
* operation 2,0 kW
EPA
ENERGY STAR ®
* Power consumption,
sleep mode 69 W
* Power consumption,
low power 362 W : recovery time 38 s
Mains connection Cable with plug/cable with fixed connection and separation switch
Safety class I (IEC 536) Protective earth connection
Protection class IP 20 (IEC 529)
Sound pressure level
(at operator position)
Standby In operation
L
pA
= 32 dB(A) L
pA
= 66 dB(A);
impulse L
i
= 4 dB(A)
Sound power level L
WA
= 48 dB(A) L
WA
= 78 dB(A);
Radio interference Complies with Directive 89/336/EEC and FCC rules and regulations, part 15 Class A.
Radiation Below the Threshold Limit Values for UV, Visible and IR radiation (TLV list of ACGIH)
Heat emission Standby 525 W; in operation 2,0 kW
Ozone emission 0,01 mg/min at continuous operation
Room volume
Recommendation: min. 35 m
3
Room ventilation Recommendation: min. 17,5 m
3
/h (natural ventilation)
For heat evacuation extra ventilation may be necessary.
Use simulation at random
operation
Room volume and ventilation as recommended
Daily copy volume (much more than average) 16500 A4
Total workt ime 8 h
Ozone concentrations:
- Time weighted average 0,001 mg/m
3
(0.0005 ppm)
- Peak 0,002 mg/m
3
(0.001 ppm)
Threshold Limit Value/Occupational Exposure Limit
(Time Weighted Average) for ozone 0,2 mg/m
3
(0,1 ppm)
Odour Perception Limit for ozone 0,04 mg/m
3
(0,02 ppm)
Consumables Océ Master (Océ Material Safety Data Sheet E-193)
Océ F11 Toner (Océ Material Safety Data Sheet E-212)
Océ Copying Materials
This apparatus is suitable for processing recycling paper which complies with the
requirements of EN 12281.
Additional safety information The ozone filter does not have to be replaced for keeping the ozone concentration in the
workplace below 0,04 mg/m
3
(the life of the filter equals that of the apparatus).
CE-Compliance Approved according to Approved according to EPA
ENERGY STA R ®
Low Voltage Directive EMC Directive
73/23/EEC 89/336/EEC
