00 - 11EN - 11
c• Raise the handlebars stem (7).
d• Raise the locking lever (6) and push it against the handlebars
stem (7) until a hooking “click” is heard.
e• Insert the brake lever (11) in the handlebars (9).
f• Adjust the position of the brake lever (11), then lock its position
using the supplied Allen key.
g• Screw the two grips (21) to the handlebars (9) as shown in the
figure.
9
9
21
21
11
11
7
7
7
