OCEAN DRIVE S9 - Closing and Transporting the E-Scooter

00 - 18EN - 18
EN
14. CLOSING AND TRANSPORTING THE
E-SCOOTER
a• Open the kickstand (2) and place the e-scooter on a flat surface.
b• Switch off the appliance by keeping the ON/OFF key (23)
pressed.
c• Grasp the handlebars stem (7) with one hand.
d• With the other hand, press on the hook (6a) and then pull the
locking lever (6).
e• Fold the handlebars stem (7) on the rear mudguard (15), then
press it downwards to hook it (until a “click” is heard).
Make sure the handlebars stem has hooked correctly to
the rear mudguard.
click !
7
7
7
15
15
23
2
6
6
6
6a
