Ocean Signal EPIRB1 Pro User Manual

27/07/2020 912S-03403-02.00 25
EPIRB1 Pro USER MANUAL
9.6 Specifi cations
406MHz Transmitter
Frequency 406.040 MHz ±1KHz
Output Power 12W EIRP
Modulation Phase ±1.1 Radians Pk (16K0G1D)
Encoding Biphase L
Rate 400 bps
121.5MHz Transmitter
Frequency 121.5 MHz
Output Power 40mW±2dB
Modulation Swept Tone AM (3K20A3X)
Modulation Depth ~97%
Frequency Stability ±50ppm
Duty Cycle ~35%
Low Duty Cycle Strobe
Light Type Dual High Intensity LED
Flash Rate 20-30 per minute
Battery
Type Lithium Manganese Dioxide (LiMnO2)
Operating Time >48Hours @ -20°C
Battery Replacement Period 10 years
GPS Receiver
Satellite Channels 66 (Acquisition)
Sensitivity -148dBm
Cold Start Re-acquisition -163dBm
GPS Antenna Microstrip Patch
General
Dimensions of Float Free Housing 237mm x 191mm x 121mm
(9.3” x 7.5” x 4.8”)
Weight 422grams (14.9oz)
IEC60945 Category Portable
Operating Temperature Class 2 -20C to +55C
Storage Temperature Class 2 -30C to +70C
Waterproof (EPIRB) 10m depth for 1 hour
Auto Release Depth 4m maximum
Approvals
Cospas Sarsat Standards T.001, T.007
Test Standards IEC61097-2, RTCM SC11000-2
