Page #10 background imageLoading...
Page #10 background image
REGULATORS
DXI INTEGRATED FIRST STAGE
© 2002 Design 2000
OCEANICOCEANIC
OCEANICOCEANIC
OCEANIC®
Product Service Guide Product Service Guide
Product Service Guide Product Service Guide
Product Service Guide
Doc. 12-2205-r01 (01/00)
PG-10
Specialty Tools
P/N 40.2302 Christo-Lube MCG111 - 2 oz
P/N 40.6536 3/8" socket drive CDx Spanner
P/N 40.9311 Filter Circlip Pliers
P/N 40.9313 5/32" Allen Key
P/N 40.9314 5/16" Allen Key
P/N 40.9315 Intermediate Press. Gauge
P/N 40.9320 1/4" Allen Key (for DIN model)
P/N 40.9520 O-ring Tool Kit
Torques
P/N 6564 Yoke Retainer 16 to 18 ft-lbs
P/N 4544 DIN Filter Retainer 120 to 140 in-lbs
P/N 6565 DIN Filter Housing 16 to 18 ft-lbs
P/N 3462 HP Port Plug 35 to 40 in-lbs
P/N 3463 LP Port Plug 35 to 40 in-lbs
P/N 6580 End cap 30 to 38 ft-lbs
P/N 6583 Environ. End Cap 30 to 38 ft-lbs
P/N 6586 Transmitter Asm 80 to 100 in-lbs
HP Hose into First Stage Body 35 to 40 in-lbs
LP Hose into First Stage Body 35 to 40 in-lbs
Inflator Hose into First Stage Body 35 to 40 in-lbs
Intermediate Pressure
Prefered 142 to 148 psi
Acceptable 139 to 151 psi
SPECIFICATIONS
