Ochsner GMLW - Technical Data GMLW

BA_GMLW OTE bis V3.4 SHORT_EN_20090408_V1 Page 19 of 25
Technical Data GMLW
Performance Data normal mode GMLW 9 GMLW 14 GMLW 19 GMLW 25
Heating Capacity L7/W35 9,9 15,1 20,2 27,0 kW
Power Consumption L7/W35 2,2 3,4 4,6 6,3 kW
Coefficient of Perfomance L7/W35 4,5 4,4 4,4 4,3
Drawn Current L7/W35 4,7 7,7 9,7 12,3 A
Heating Capacity L2/W35 8,5 12,7 17,0 22,4 kW
Power Consumption L2/W35 2,0 3,25 4,35 5,9 kW
Coefficient of Perfomance L2/W35 4,2 3,9 3,9 3,8
Drawn Current L2/W35 4,6 7,5 9,8 12,1 A
Heating Capacity L2/W50 7,8 11,5 15,6 21,4 kW
Power Consumption L2/W50 3,25 4,7 6,4 8,7 kW
Coefficient of Perfomance L2/W50 2,4 2,4 2,4 2,45
Drawn Current L2/W50 6,0 9,0 11,8 15,0 A
Performance Data reverse mode
Cooling Capacity L30/W18 5,9 8,9 12,1 15,1 kW
Waste heat Cpacity L30/W18 8 12,0 16,4 20,4 kW
Power Consumption L30/W18 2,0 3,1 4,3 5,3 kW
Coefficient of Performance L30/W18 3 2,9 2,8 2,8
Drawn Current L30/W18 4,3 6,8 9,0 12,8 A
Compressor
Type
Number 1111units
Max. Operating Current 8,0 13,0 16,0 20,0 A
Max. Starting Current 31 45 68 90 A
Max. Starting Current w/ Discharge 16 23 34 45 A
Evaporator
Type
Building Material
Number 1111units
Max. Operating Pressure Antifreeze 30 30 30 30 bar
Relative Humidity 80% 80% 80% 80%
Air Volume Flow Rate 4000 4000 8000 8000 m³/h
Working Fluid Temperature Difference 5,0 5,0 5,0 5,0 K
Operating Range -15/+40 -15/+40 -15/+40 -15/+40 °C
Fan Power Consumption 140 140 280 280 W
Noise pressure level
(in a distance of 10m)
26 26 29 29 dB(A)
Weight 94 94 126 141 kg
Condenser
Type
Building Material
Number 1111units
Max. Operating Pressure Water 6666bar
Max. Operating Pressure Antifreeze 30 30 30 30 bar
Internal Pressure Differenze 0,07 0,1 0,17 0,2 bar
Working Fluid Volume Flow Rate 1,7 2,6 3,5 4,64 m³/h
Durchmesser Anbindeleitung 27,41 33,90 39,34 45,29 mm
Static Pressure Head w/out redirect valve max. 0,247 0,071 0,112 - bar
Fitting Diameter (minimum) 28 35 42 54 mm
Working Fluid Temperature Difference 5555K
Operating Range 55 55 55 55 °C
Working Fluid
Rated Pressure 45 45 45 45 bar
Refrigeration Cycle
Number of Refrigeration Cycles 1111units
Working Fluid R 407C R 407C R 407C R 407C
Defrost Function
Unit Data/ Electriacal Information
Voltage/ Frequency 400/50 400/50 400/50 400/50 V/Hz
Power Factor (cosine Phi) 0,68 0,64 0,68 0,74
Fuse Protection 10 16 20 25 A
Hood Color
Housing Color
Weight 120 130 143 156 kg
Built-in Heating Circulation Pump yes yes yes no
Hot gas / Reversal System
grey/white RAL 9002
cement grey RAL 7030
Stainless Steel 1.4401
Water
Copper / Aluminium
Flat Plate Heat Exchanger
Full-hermetic / Scroll
Finned Heat Exchanger
