Technical Data GMLW plus
Performance Data normal mode
GMLW 9 Plus
GMLW 14 Plus GMLW 19 Plus GMLW 25 Plus
GMLW 35 plus
Heating Capacity L7/W35 10,0 14,1 19,8 26 34,8 kW
Refrigerating Capacity L7/W35 7,8 11,1 15,4 20,4 27,7 kW
Power Consumption Compressor L7/W35 2,2 3 4,4 5,6 7,1 kW
Power Consumption Fan L7/W35 0,14 0,115 0,23 0,23 0,60 kW
Power Consumption L7/W35 2,3 3,1 4,4 5,8 7,7 kW
Coefficient of Perfomance L7/W35 4,4 4,5 4,5 4,5 4,5
Drawn Current L7/W35 4,6 6,4 8,6 11,8 16,3 A
Heating Capacity L2/W35 8,6 11,7 16,8 22,1 29,5 kW
Refrigerating Capacity L2/W35 6,5 8,8 12,6 16,8 22,7 kW
Power Consumption Compressor L2/W35 2,1 2,9 4,2 5,3 6,9 kW
Power Consumption Fan L2/W35 0,14 0,115 0,23 0,23 0,60 kW
Power Consumption L2/W35 2,2 3,0 4,3 5,6 7,5 kW
Coefficient of Perfomance L2/W35 3,9 3,9 3,9 3,9 3,9
Drawn Current L2/W35 4,5 6 8,3 11,6 16,1 A
Heating Capacity L2/W50 8,1 10,7 15,9 19,7 27,0 kW
Refrigerating Capacity L2/W50 5,3 7 10,3 12,6 17,6 kW
Power Consumption Compressor L2/W50 2,8 3,7 5,6 7,1 9,4 kW
Power Consumption Fan L2/W50 0,14 0,115 0,23 0,23 0,60 kW
Power Consumption L2/W50 2,9 3,8 5,7 7,3 10,0 kW
Coefficient of Perfomance L2/W50 2,8 2,8 2,8 2,7 2,7
Drawn Current L2/W50 5,2 7,2 10 13,6 19,2 A
Performance Data reverse mode
Cooling Capacity L30/W18 9,9 8,7 13,3 14,8 28,4 kW
Waste heat Cpacity L30/W18 12,7 11,9 18,2 20,3 20,9 kW
Power Consumption L30/W18 2,9 3,2 4,9 5,5 8,1 kW
Coefficient of Performance L30/W18 3,4 2,7 2,7 2,7 3,5
Drawn Current L30/W18 5,9 6,5 8,9 13 16,0 A
Compressor
T
y
pe
Number 11111units
Power settings 1 1 1 1 1 units
Max. Operating Current 6,0 9,6 13,8 17,7 23,2 A
Max. Starting Current 28,0 45 49,5 70 90,0 A
Max. Starting Current w/ Discharge 14,0 23 25 35 45,0 A
Evaporator
Type
Building Material
Number 11111units
Max. Operating Pressure Antifreeze 30 30 30 30 30 bar
Relative Humidity 80% 80% 80% 80% 80%
Air Volume Flow Rate 4000 4000 8000 8000 9800 m³/h
Working Fluid Temperature Difference 4,0 5,0 5,0 5,0 4,0 K
Operating Range -18/+40 -15/+40 -15/+40 -15/+40 -18/+40 °C
Fan Power Consumption 140 140 280 280 600 W
Noise pressure level
(in a distance of 10m)
26 26 29 29 37,5 dB(A)
Weight 94 94 126 141 159 kg
Condenser
Type
Building Material
Number 11111units
Max. Operating Pressure Water 6 6 6 6 6 bar
Max. Operating Pressure Antifreeze 30 30 30 30 30 bar
Internal Pressure Differenze 0,07 0,09 0,16 0,17 0,22 bar
Working Fluid Volume Flow Rate 1,7 2,5 3,4 4,4 6 m³/h
Durchmesser Anbindeleitung 27,53 33,25 38,77 44,10 51,36 mm
Static Pressure Head w/out redirect valve max. 0,247 0,071 0,112 - - bar
Fitting Diameter (minimum) 28 42 42 54 54 mm
Working Fluid Temperature Difference 5 5 5 5 5 K
Operating Range 65 65 65 65 65 °C
Working Fluid Water Water Water Water Water
Rated Pressure 45 45 45 45 45 bar
Refrigeration Cycle
Number of Refrigeration Cycles 1 1 1 1 1 units
Working Fluid R 407C R 407C R 407C R 407C R407C
Defrost Function
Unit Data/ Electriacal Information
Voltage/ Frequency 400/50 400/50 400/50 400/50 400/50 V/Hz
Power Factor (cosine Phi) 0,72 0,72 0,76 0,69 0,71
Fuse Protection 16 16 20 25 25 A
Hood Color
Housing Color
Weight 117 130 143 166 160 kg
Built-in Heating Circulation Pump yes yes yes no no
Hot gas / Reversal System
cement grey RAL 7030
grey/white RAL 9002
Copper / Aluminium
Flat Plate Heat Exchanger
Full-hermetic / Scroll
Finned Heat Exchanger
Stainless Steel 1.4401
