9 Use of the BIOM® 5
Instruction Manual BIOM® 5 (G/55400/1218/en) 17 / 36
For BIOM
®
5c/cl only
For the BIOM® 5c/cl, you must connect the control cable with the SDI®
4c or BIOM® connecting spacer.
 Plug the control cable into one of the side sockets on the SDI® 4c or
BIOM® connecting spacer.
Make sure that the cable does not come into contact with any
unsterile parts of the microscope.
 Connect the cable to the SDI® 4c or BIOM® connecting spacer. The
connector locks automatically.
Fig. 9-6: BIOM® 5c/cl: Connecting the control cable (example: SDI® 4c)
