OCULUS BIOM 5ml User Manual

10 Troubleshooting
24 / 36 Instruction Manual BIOM® 5 (G/55400/1218/en)
Unclear image  Soiled glass surfaces
 The glass surfaces have been
damaged during sterilisation
 The glass surfaces have been
mechanically damaged
 Ophthalmoscopy loupe is
touching the eye
 Dry patient cornea
 Clean the glass surfaces
 Change the sterilisation
method, replace lenses if
necessary
 Greater care in use and
storage of lenses; replace if
necessary
 Choose the correct work
distance, clean the loupe
 Moisten the cornea regularly
with a suitable solution
Unfocussed image  Incorrect adjustment of the
BIOM® 5
 A reduction lens is not being
used
 The reduction lens is not
compatible with the
microscope objective
 Focus the BIOM® 5 in
accordance with the
instructions
 Use a reduction lens
 Check the engraving on the
reduction lens and exchange
the reduction lens, if
necessary (see sec. 9.1,
page 11
Fundus view is too narrow  Too much distance between
the ophthalmoscopy lens and
the eye
 Magnification of the
microscope system to high
 Carefully reduce the distance
using the microscope fine
adjustment mechanism
 Reduce magnification of the
microscope
The eye or the lens reflects strongly  The microscope light is on  Turn the light off, illuminate
only intraocular
The BIOM® 5 cannot be detached
from the adaptor
 BIOM® 5 has not been tilted
to the side
 Mineral deposits on the
connection components of
the BIOM® 5 and adaptor
 Tilt the BIOM® 5 to the side
 Place the BIOM® 5 and
adaptor into an ultrasound
bath (for approx. 5 min)
Fault Possible cause Remedy
