LA715
2 User ManualP2640300
1.KEYBOARD AND LED INDICATORS
The frontal panel has a red led display with digit h. 20 mm and 4 led indicators and a touch
keyboard with 12 keys.
1.1 Led Indicators
If led is on, the weight is between –1/4 ÷ +1/4 of zero
If led is off , the weight is steady
If led is on , the SW21 is working with internal battery; if led is blinking, the battery
is low and need to be recharged through the charger
If led n° 1 is on , the scale is in the first weighing range
If led n° 2 is on , the scale is in the second weighing range
If both of them are on , the scale is in the third weighing range
