LA715
1 User ManualP2640300
TECHNICAL CHARACTERISTICS
POWER SUPPLY 230Vac +/-10% , 50-60Hz with external power
device 7,5Vdc/1900mA or optional rechargeable
battery (6 V – 3,2 Ah).
MAXIMUM ABSORPTION 4 W
WORKING TEMPERATURE From -10 to +40 °C.
READABILITY Max 60000 divisions
LEGAL DIVISIONS Max 10000 or 2x6000 or 3x3000 .
DISPLAY Red LED 6 digit display, h 20 mm .
LED 4 Status LED
KEYBOARD Touch keyboard with 12 keys.
LOAD CELL POWER SUPPLY 5Vdc ± 5%, 120mA (max 8 load cell 350 Ohm).
LOAD CELL CONNECTION 6 wires with Remote Sense.
CASE Stainless steel case with optional wall or column
bracket.
SERIAL OUTPUT 2 input/output RS232 for PC, printers or weight
repeaters
USB OUTPUT 1 USB Output for PC and Pen Drive
OPTIONS Internal rechargeable battery ( autonomy 12 h )
Output card with n° 2 outputrelè
Optional card with fiscal memory
Ethernet output for LAN connection
