8.ENGINE
8-7
1. Plug screw
2. Gasket ring
3. Pressure regulator housing
4. Spring
5. Pressure regulator valve
Inspecting the Oil Pressure Regulator
Inspect pressure regulator housing and
valve for scoring or other damages.
Check spring for free length.
NOTE: Replace worn or damaged
components.
Clean bore and thread in the magneto
housing from metal shavings and other
contaminations. Installating Oil Pressure
Regulator
For installation, reverse the removal
procedure.
Pay attention to the following details.
NOTE: At installation always replace the
gasket ring of the plug screw by a new
one.
OIL PUMP
Oil Pump Location
The oil pump is located on the engine
PTO side
(behind PTO cover).
1. Oil pump
Oil Pump Removal
Remove the PTO cover. Refer to PTO
COVER in the BOTTOM END subsection.
1. Remove:
