Too low cylinder pressure may cause the
following:
Excessive wear to cylinder;
Wear to piston or piston ring;
Blockage of piston ring in groove;
Close valve seat;
Damage to cylinder lining or faults of
other parts.
Measure engine compression pressure:
1. Warm up engine.
2. Ensure full charging of battery.
3. Remove the relevant plastic parts and
accessories from the outside of the
engine.
4. Dismantle spark plugs.
5. At spark plug hole, install cylinder
pressure meter.
6. Press button of start for several seconds.
Record indication of maximum cylinder
pressure.
Check the engine oil pressure periodically.
This will give a good indication of the
condition of the moving parts. The engine
oil pressure test should be done with a
warm engine 90℃ and the recommended
oil.
GEARBOX
Verifying the Gearbox Oil Level
Tilt the cargo box.
Unscrew and remove the gearbox oil
dipstick wipe clean.
NOTICE: Pay attention not to loose O-ring
on oil dipstick.
1.Gearbox oil dipstick
Reinstall dipstick, screw in it completely.
Remove dipstick again and check oil level. It
should be near or equal to the upper mark.
1.MAX.
2.MIN.
3.Operating range
To add oil, place a funnel into the dipstick
hole. Add a small amount of recommended
oil and recheck oil level.
Repeat the above procedures until oil level
reaches the dipstick's upper mark.
NOTICE: Operating the gearbox with an
improper oil level may severely damage
gearbox.
NOTE: Do not overfill. Wipe off any spillage.
Properly tighten oil dipstick.
Replace gearbox oil
Prior to change the gearbox oil, ensure
vehicle is on a level surface, should be done
with a warm engine.
1. Ensure vehicle is on a level surface.
2. Drive vehicle for a few minutes.
To Next Page
