3. Stop engine and wait a few minutes.
4. Remove engine shield
5. Remove the oil level check plug.
6. Place an oil pan under the gearbox case,
and then drain oil completely by removing
the drain plug.
7. Tighten the drain plug to 20 N.m.
8. Pour the specified oil(GL-4-90) about
420mL by syringe through the oil level
check plug hole until the oil over flows.
9. Tighten the oil level check plug to 20
N.m.
Place a drain pan under the gearbox drain
plugarea.
1. Oil drain plug
Clean drain plug area. Remove magnetic
drain plug and discard sealing ring.
Clean drain plug area.
Remove oil dipstick.
NOTICE: Pay attention not to loose O-ring
on oil dipstick.
Wait a while to allow oil flow out of
gearbox.
1.Magnetic drain plug
2.Sealing ring
Dispose gearbox oil as per your local
environmental regulations.
