SHIFTER
NOTICE ： If it is necessary to disassemble
the dashboard to maintain gear shifting or
other mechanisms, please remove the four
bolts (including the left and right sides)
indicated by the arrows at the front of the
roof to remove the dashboard. (Other bolts
on the ceiling do not need to be removed)
SHIFT LEVER
Shift Lever Access
1. remove the following components:
- Shifter indicator
Shift Lever Removal
1. Remove body parts as required. Refer to
SHIFT LEVER ACCESS in this subsection.
2. Place shift lever in NEUTRAL position.
3. Secure vehicle using wheel blocks.
4. Unscrew shift lever handle.
5. Detach shifter cable from shift lever by
removing nut and washer.
Shift Lever Inspection
Check shift lever for bending or cracks.
Check spring and bushing condition.
Replace all damaged parts.
Shift Lever Installation
The installation is the reverse of the removal
procedure. However, pay attention to the
following. Ensure shift lever angle is within
specifications.
