C-Arm Subsystem
The following table lists the primary components of the C-Arm, associated with the major assemblies shown in the previous
diagram, for the purpose of indicating physical location.
Location Major Assemblies
Control Panel Housing Assembly Left and Right Hand Control Panels
Control Panel Processor I/O PCB
Control Processor Assembly
Vacuum Fluorescent Display (VFD) Modules (2)
Camera Cover CCD Camera
Image Intensifier
Vertical Column Lift Column
L-Rotation Assembly L-Arm Mechanical Assembly
Gas Shock
Collimator Cover Primary and secondary Collimator
X-ray Tube Cover Thermal Switch
Temperature Sensor
X-ray Tube
Front Top Cover Power/Motor PCB
Front Leg Cover Front Caster
Steering Chain
Cable Pushers
Right Front Cover Capacitor/Power Module
Left Front Cover Stator/Pre-charge Transformer
Multi-output Transformer (PS 2)
Capacitors, Motor AC (2)
Power/Signal Interface PCB
Power Supply, +5/+12/±15 VDC (PS1)
Cross Beam End Cap (left and right
sides)
Part of rear steering system
12
