X-ray On, X-ray Disable
Signame Source Destinatio
n
Activ
e
Pull-
up
Effect of open fault
XRAY_ON* XR Ctrlr HV Sup
Reg
L Y PWM chip disabled
Gen Drvr L Y Stops fault sensing
XRAY_ENABLE* XR Ctrlr HV Sup
Reg
L Y Forces KVP_PULSE low
Gen Drvr L Y Disables kVp drivers
SHUTDOWN XR Ctrlr HV Sup
Reg
H Y Disables
KVP_DRV_RTN
Gen Drvr H Y Disables kVp drivers
ANALOG_RTN XR Ctrlr Gen Drvr GND N Direct ground return
FIL_DRV_A* XR Ctrlr Gen Drvr L Y No fil. drv, FIL_DR_OK*
hi
FIL_DRV_B* XR Ctrlr Gen Drvr L Y No fil. drv, FIL_DR_OK*
hi
FIL_SELECT XR Ctrlr Fil Drvr H PD Sm fil selected
FAULT_RST XR Ctrlr HV Sup
Reg
H PD Does not reset faults
Gen Drvr H PD Does not reset faults
HV_GEN_ON* Fil/Gen
Drvr
XR Ctrlr L Y Software input
INTLK_CMPLT* Fil Drvr HV Sup
Reg
L Y Disables
KVP_DRV_RTN
Gen Drvr L N Passes through
10
