Image Control
Image Intensifier and Power Supply
Failure Possible Cause Remedy
No Image on Monitor. Bad II or Power Supply, Bad Camera, Bad Monitor. Does kV track to 120? If yes check CCD
Camera and output of II.
Image out of Focus II Power Supply, II tube problems, CCD Camera Check if II and Camera can be focused.
Check all MAG sizes
Adjustments
(see Calibration section)
Miscellaneous
CCD Camera
8
Service
Periodic Maintenance
