Image Control
Test
Point
Description
Test
Point
Description
1 5V_MOTOR_PWR 23 -12VDC
2 CPU DC 24 VR1 OUT
3 CPU RESET 25 CAM_COMM+
4 20 MHz CLOCK (ARCNET) 26 CAM_COMM-
5 ARC_INT (ARCNET) 27 +12 vdc
6 ARCNET_LO (ARCNET) 28 POS_15V (Filtered)
7 ARCNET_HI (ARCNET) 29 Y1 ENABLE
8 CPU_RD-WR 30 VCC +5VDC
9 Pin 68-Pin 33 Loop (ARCNET) 31 GND
10 16 MHz CLOCK 32 INT_FS
11 16 MHz CLOCK (U48) 33 INT_ARC
12 CPU AS 34 CAM_ROT (Position Filters)
13 LIM_REF (Motor Limit) 35 CAM_IRIS (Position Filters)
14 FRAME_SYNC_LO (ARCNET) 36 CAM_ROT (Position Filters)
15 INT_FSYNC (ARCNET) 37 COL_WIDTH (Position Filters)
16 FRAME_SYNC_HI (ARCNET) 38 COL_IRIS (Position Filters)
17 CPU PBRST 39 SPARE_CH (Position Filters)
18 AGND 40 FLD_SIZE (Position Filters)
19 WD_STRB 41 COOLER_PWR_MON
20 TRI-ST (ARCNET Chip Select) 42 GND
21 Not Used 43 GND
22 NET_15V (Filtered) 44 GND
