Wig Wag Motion
Circuit/Mechanical Descriptions
The entire C-Arm can pivot laterally (wig wag) ±10 degrees as shown in the following illustration. A brake assembly allows you to
pivot the C-Arm to a convenient position and then lock it in place.
Wig-wag Brake
+ 10 Degrees
Wig Wag Motion and Brake
