OEC 9800C-Arm - Page 225

L-Arm Motion
6. Adjust the position of the second brake handle so that both handles have the same angular position.
7. Retest the brake.
If brake does not engage even after brake handle position adjustment, replace the L-Arm brake shoe. (Refer to Replacement
chapter in this manual for details.)
Miscellaneous
Not applicable.
