Steering and Braking
8. Install end cap and screw you removed in step 3.
9. Remove jack from C-Arm axle and check brakes for proper operation.
Adjustment Brake
Plunger
Brake Plunger
Yoke Bearing Housing
Compression Spring
Cylinder Bearing
Rear Wheel Yoke
Wheel
Set Screw
Adjustment
Brake
Plunger
Rear Wheel Brake Details
