Diagnostics
Channel # Message Signal Name Pin and Reference
0 Housing Temperature HSNG_TEMP P1-85, 86
1 Stator Sense STATOR_SEN P1-108, 109
2 Spare; not used None None
3 Filament B FIL_B_SEN P1-50, 51
4 Flux Sense FLUX_SEN P1-56, 57
5 Filament Current FIL_CUR P1-52, 53
6 Filament Voltage FIL_VOLT P1-54, 55
7 Charge Current CHRG_I_SEN P1-78, 80
8 Line Voltage LINE_V_SEN P1-75, 80
9 kVp KVP_SEN P1-72, 73
10 Low mA LO_MA_SEN P1-70, 71
11 High mA HI_MA_SEN P1-68, 69
12 Inverter B INV_B_SEN P1-48, 49
13 kVp Feedback KVP_CTL P1-24, 25
14 Filament B Feedback FIL_B_CNTL P1-37, 38
15 Test DA Sense TEST_DA U34-7
Generator Processing
The generator performs a number of processing activities under program control. The following paragraphs discuss these
processes.
Filament Control
There are two filaments in the X-ray tube, the “large” filament and the “small” filament. System software ensures that only one
filament is on at a time. It also determines which filament is selected, preheats it, and determines the duty cycle.
14
