OEC 9800C-Arm - Page 270

Diagnostics
Message Type or Code Data Item
2- Desired kV
KV ON IN ERROR – POWER OFF, WAIT 5
SECONDS
Error 1-Sensed kV
2-None
LIFT SWITCH STUCK – PRESS ANY KEY Error 1-None
2-None
WARNING, HIGH MA – PRESS ANY KEY Error 1-Sensed mA 2-2-Desired mA
MA SENSOR FAIL Error 1-Sensed mA
2- Desired mA
WARNING, LOW MA – PRESS ANY KEY Error 1-Sensed mA
2-Desired mA
MA SENSOR FAILE Error 1-Sensed mA
2-Desired mA
MA ON IN ERROR – POWER OFF, WAIT 5
SECONDS
Error 1-Sensed mA
2-None
OVERLOAD FAULT Error 1-High Voltage Input Register reading
2-None
OVERVOLTAGE FAULT Error 1-High Voltage Input Register reading
2-None
PLEASE WAIT Operation 1-None
2-None
PRECHARGE CIRCUIT TIMEOUT – POWER
OFF. WAIT 5 SECONDS
Error 1-Inverter B (Battery Voltage)
2-None
24 HOUR RECHARGE REQUIRED – X-RAYS
DISABLED
Error 1-Inverter B (Battery Voltage)
2-None
20
