Diagnostics
HEX
DISP
FLUORO FUNCTIONS PCB SOFTWARE STATE
01 Checking Flash
02 Initializing processor
03 Clearing Memory (BSS1)
04 Clearing Memory (BSS2)
05 OS initializing
06 Application Initialization beginning
07 Architecture utilities initializing
08 Network Initialization
09 Timers being initialized
0A Tasks Initializing
FE Fatal Error (System halted - Stack overflow, no memory, unhandled interrupt)
0D,FF System halted (Out of Memory)
E0,XX,FF ARCNET transmit pipe temporarily full
E4 Stack Memory dangerously low
The above table gives the codes output to the 2-digit Hexadecimal display on the Fluoro Functions PCB. 01-0A are sequential codes output
board initialization. The remaining codes represent error conditions.
34
