Refer to Workstation Interconnect Diagram 00-878981 as you read this section.
Major Functions
The OEC Workstation provides most of the user interfaces and all of the external data interfaces in an OEC mobile
digital imaging system. It also performs the system’s computing and image manipulation functions such as post
processing and storage. The Workstation also provides AC power conversion, distribution, and monitoring, directs
many automated functions, and reports system conditions to the operator to ensure safe and accurate system
operation.
Physically, the Workstation consists of two high-resolution video monitors mounted on a moveable cart equipped with
a keyboard and other user interfaces. The AC line cord that powers the Workstation and image generator enters the
rear of the Workstation, as does the system interconnect cable that carries power to, receives video from, and
exchanges data with the X-Ray generator. The Workstation contains many electronic assemblies, and can be
equipped with optional devices such as a VCR or dye diffusion printer.
When the Workstation connects to an X-Ray generator, it can capture and process live fluoroscopic images. It can
also be used as a standalone device for viewing and postprocessing stored images.
A typical Workstation appears on the following page.
