OEC 9800C-Arm - Page 344

Calibration
Mag 2 Field Size
2
34
1
50
Collimator Iris may only
be partially visible.
(1 or 2 leaves)
Circular
Blanking
Mag 2 Field Size
19. Develop the film.
20. Use the ruler marks that intersect the center of the flat portion of the collimator iris to determine the X & Y film diameters.
60
