Replacement
Power Signal Interface PCB Fuses
Ref Des Capacity Part Number Purpose
F10 2.0A 55-500344-00 Protects the 115VAC_PH_PS2 line (P9-7) that supplies AC power from
fuse F6 to Power Supply PS2.
F11 3.15A 55-500345-00 Protects the +24V_PS2 line (P9-12) from Power Supply PS2. This line
supplies +24 Volts to the Power/Motor Relay PCB (P8-8).
F12 3.15 55-500345-00 Protects the +5V_PS1 line (P4-1, 2, 3) that supplies +5 Volts from
Power Supply PS1 to the Control Panel Processor I/O PCB (P6-1, 2, 3).
F13 2.0A 55-500344-00 Protects the +6.0_PS2 line (P9-1, 8) that supplies +6.0 Volts from
Power Supply PS2 to the CCD Camera (P7-1, 5).
F14 1.0A 55-500343-00 Protects the -6.0_PS2 line (P9-2, 9) that supplies -6.0 Volts from Power
Supply PS2 to the CCD Camera (P7-2, 6).
F15 0.8A 55-500350-00 F15 is a 0.8A fuse that protects the +14V_PS2 line from Power Supply
PS2 (P9-3) to the CCD camera (P7-3).
F16 0.5A 55-500349-00 Protects the -14V_PS2 line from Power Supply PS2 (P9-10) to the CCD
camera (P7-7).
30
