The Display Adapter PCB translates the 25 or 30 FPS 1024 x 1024 pixel images generated in the Image Processor to
60 or 75 FPS non-interlaced video for output to the high-resolution display monitors. The Display Adapter also
converts the non-interlaced Image Processor video to standard resolution interlaced video that is compatible with PAL
or NTSC video cassette recorders and monitors.
User Interfaces
The Workstation’s user interface includes the Control Panel Processor (a PCB that mounts below the Keyboard),
Keyboard, Infrared Receiver and Handheld Transmitter, Touch Screen, XRAY ON indicator, and ON/OFF pushbutton.
Refer to Section 8 - User Interface for detailed circuit descriptions, troubleshooting information, and component
replacement instructions.
