Vascular
The Vascular Workstation has the same features as the ESP - Cine Workstation described above, plus the ability to
perform digital subtraction and roadmapping. The Vascular Workstation also offers the Landmark feature that displays
a variable percentage of background in a subtracted image, Mask Registration to realign a mask with a subtracted
image, and Peak Opacification to improve the contrast of a subtracted image.
Neurovascular
The Neurovascular Workstation is similar to the Vascular Workstation, except that it has 30 FPS, 5-minute Cine
capability. High-Level fluoro and the 30 PPS option are not available. The removable zip disk is an option.
Cardiac
The Cardiac Workstation offers 30 FPS, 5 minute Cine Disk capability, High-Level fluoro, and the removable zip disk
as standard features. The 30 PPS option is also available in the Cardiac Workstation.
Options
The following optional equipment is available for the OEC Workstation.
Cine Disk
The Digital Cine option offers high technique levels for imaging small vessels and other anatomy that is in constant
movement. The 15 FPS option stores high resolution images at up to 15 images per second (12.5 FPS at 50 Hz) for
up to five minutes. The 30 FPS option stores images at up to 30 images per second (25 FPS at 50 Hz) for up to five
minutes.
For more information, refer to CINE DISK SUBSYSTEM, which appears earlier in this section, or to Section 6 -
Cine Disk Subsystem.
