Operating Instructions and Parts Manual 24813
09/14
2014 ©OEM-TOOLS
PRESS PIN SET
Figure Description Quantity
24813-1 Press Pin 2 Ton 1
24813-2 Press Pin 3 Ton 1
24813-3 Press Pin 8 Ton 1
24813-4 Press Pin 12 Ton 1
24813-5 Press Pin 14 Ton 1
24813-6 Press Pin 16 Ton 1
24813-7 Press Pin 18 Ton 1
24813-8 Press Pin 20 Ton 1
24813-9 Adapter 1
24813-10 Bracket 1
24813-11 Mounting Plate 1
The manufacturer and/or distributor have provided
the parts list and assembly diagram in this manual as
a reference tool only. Neither the manufacturer nor
distributor makes any representation or warranty of any
kind to the buyer that he or she is qualified to make any
repairs to the product, or that he or she is qualified to
replace any parts of the product. In fact, the manufacturer
and/or distributor expressly states that all repairs and
parts replacements should be undertaken by certified
and licensed technicians, and not by the buyer. The
buyer assumes all risk and liability arising out of his
or her repairs to the original product or replacement
parts thereto, or arising out of his or her installation of
replacement parts thereto.
MAINTENANCE
Before each use, inspect Press Pin Set for damage. Do
not use if bent, broken, cracked, leaking or otherwise
damaged components are noted.
1 2 3 4 5 6 78
9
10
11
Note: Not all components of the Press Pin Set
are replacement items, but are illustrated as a
convenient reference for location and position in the
assembly sequence
