Operating Instructions and Parts Manual 24500
1.8 CFM SINGLE STAGE
VACUUM PUMP
03/14
2014 ©OEM-TOOLS
Specifications
Model Number 24500
Stages 1
Motor Size (HP)
RPM @ 50/60Hz
1.8 CFM / 1/4 HP
2880 / 3440
Dimensions (Inches) 9.4 x 3.6 x 7.8
Weight 8.1 lb / 3.6 kg
Operating Temperature
Range
0˚C (32˚F) to 52˚C (125˚F)
Power Source 115 VAC 50 - 60Hz
Ultimate Vacuum as low as 75 Microns
Oil Capacity 6.5 oz / 200 ml
Construction
Heavy Gauge Aluminum Chasis with reinforced base and
rubber lined steel handle
Overload Protection
Motor Thermally Protected, Dual Voltage units have
extra IEC fuse
Control System ON-OFF power switch
Intake Fittings 1/4" SAE and 1/2" ACME Male
Free Air Displacement 1.8 CFM @ 60Hz - 48 l/m @ 50Hz
