8
Operating Instructions and Parts Manual 24500
1.8 CFM SINGLE STAGE
VACUUM PUMP
03/14
2014 ©OEM-TOOLS
Routine Maintenance
It is recommended to change the vacuum pump oil after 50 hours
of usage. The purity
of the oil will determine the final vacuum level achieved. Always use the recommended
vacuum pump oil. The oil provided with the pump has been specially blended to maintain
maximum viscosity at normal running temperatures as well as cold weather starts.
OIL CHANGE PROCEDURES:
1. Be sure the pump oil is warmed up. if not warm, turn vacuum pump “ON” for 10
minutes.
2. Make sure vacuum pump is not plugged in.
3. Remove the oil drain cap and drain the contaminated oil into a suitable container. Tilt
the vacuum pump toward the oil drain port.
4. Once all the oil has been drained, re-secure the oil drain cap back onto the oil drain
port.
5. Remove the exhaust / oil fill cap and add oil until it is seen in the middle of the oil sight
glass. Re-secure exhaust/oil fill cap.
