Oemtools 24815 - Parts List

7
Operating Instructions and Parts Manual 24815
SANDBLAST BENCH TOP CABINET
5/19
2019 OEMTOOLS™
PARTS LIST AND DIAGRAM
Item Description Part No. Item Description Part No.
1 Grid 24815-01 24 End Cap 24815-24
2 Fluorescent Tube 12V 24815-02 25 Abrasive Nozzle 4mm 24815-25A
3 End Connector 24815-03 25 Abrasive Nozzle 5mm 24815-25B
4 Plastic cover 24815-04 25 Abrasive Nozzle 6mm 24815-25C
5 Input Cable Assy*
1
24815-05 25 Abrasive Nozzle 7mm 24815-25D
6 Cable Gland assembly 24815-06 26 Air Nozzle N/A
7 Power Cable Assembly*
2
24815-07 27 O-Ring 24815-27
8 Main Filter 24815-08 28 Push Rod 24815-28
9 Secondary Filter 24815-09 29 Return Spring 24815-29
10 Retaining disc. 24815-10 30 Abrasive Intake Hose 24815-30
11 Rubber Gloves (pair) 24815-11 31 Air Hose Adapter 24815-31
12 Worm Drive Clip 24815-12 32 Worm Drive Clip 24815-32
13 Clear Plastic Lid 24815-13 33 Air Hose 24815-33
14 Knob 24815-14 34 Flat Washer 24815-34
15 Lid Retaining Chain 24815-15 35 Adapter Nut 24815-35
16 Clear Plastic Window 24815-16 36 Gun*
3
24815-36
17 Window Retaining Strip 24815-17 37 O-Ring 24815-37
18 Lid Hinge 24815-18 38 Plug 24815-38
19 Florescent Tube Clip 24815-19 39 Adapter 24815-39
20 Air Vent Foam Packing 24815-20 40 Abrasive Pickup 24815-40
21 Lid Swivel Clamp 24815-21 41 Worm Drive Clip 24815-41
22 Cable Connection Box 24815-22 42 Grid Foot 24815-42
23 Cabinet only (minus lid) 24815-23
*1 - comprising; wiring, plastic end cover and reflector.
*2 - comprising; cable, transformer with 3-pin plug and connector.
*3 - includes items 24 and 26
