Oertzen E 334 - Electric Wiring Diagrams; Technical Data

13
6.
Electric Wiring Diagrams
7. Technical Data
Technical Data E 334
Water flow/adjustable 1000 – 2020 l/h
Unloading pressure 230 bar
Working pressure/adjustable 210 bar
Normal current (50 Hz) 3 ~ 400 V
Electric power 15 HP/12,5 kW
Pump speed 1420 1/min
Power consumption 24 A
Noise level Lp/Lw acc. to DIN EN ISO 3744 69/81 dB(A)
Recoil 116 N
Dimensions (L x W x H mm) 780 x 690 x 800 mm
Weight 146 kg
Spray nozzle 1033 HIP
Order No. 10.000.334
