13
REBUILD AIR SPRING CARTRIDGE
17
18
17. Use a 19/24 mm wrench to loosen the seal head. Slide the cylin-
der tube off the air spring.
18. Remove the two old o-rings (00638-86) from the upper air
chamber cylinder tube.
19. Install two new o-rings (00638-86) on the upper air chamber
cylinder tube. Apply assembly grease on o-rings.
20. Remove the old o-ring (18637-01) from the piston.
21. Remove the the two old back-up rings (18556-03).
19
20
21
